FREQUENCY HOPPING
Figure 119 shows the relationship between Hop 1 and Hop 2 signals in a dual-hop mode of operation. Hop 1 and Hop 2 are triggered
independently but must not be triggered at the same time. There must be a minimum of 12 µs offset between Hop 1 and Hop 2 edges. The
timing of the channel setup signals is the same as the 'PLL Retune Mode'.
PLL Retune
In the PLL Retune mode, the time to the start of the Rx/Tx analog front end being powered up is the maximum of: t
and t , where t
chRiseToAnaOn FHProcessing
variable per profile between ~150 MHz and ~200 MHz. Retrieve the system clock for a desired profile from the 'TDD Enablement Delay' tab
in TES. t could be measured for a particular system clock by comparing the transition times between two profiles and subtracting
FHProcessing
the PLL retune time using the measurement described in the
t = 26.7 µs, and when system clock = 192 MHz, t
FHProcessing
Table 54. PLL Retune Time (PLL Calibration Mode = Fast)
Device Clock (MHz)
30 92.6
38.4 73.2
50 56.7
100 34.6
150 26
200 21.3
245.76 18.7
300 16.1
Table 55. PLL Retune Time (PLL Calibration Mode = Normal)
Device Clock (MHz)
30 380.3
38.4 347.4
50 327.7
100 291.2
