PRODUCT HIGHLIGHTS
The ADRV9006 does not support the fast profile switching functionality.
►
The ADRV9006 does not support the digital predistortion functionality.
►
The ADRV9006 does not support the monitor mode functionality.
►
The ADRV9006 only supports the Low Power ADC functionality.
►
The ADRV9006 does not support the external LO functionality.
►

ADRV9001 PRODUCT FAMILY COMPARISON

Table 1 shows the differences between all products in the ADRV9001 family.
Table 1. ADRV9001 Product Family Comparison
Feature ADRV9002
Channel Count 2T2R
RF Range 30 MHz to 6 GHz
Bandwidth 12kHz to 40 MHz
Rx Tracking Cals Yes
Tx Tracking Cals Yes
Frequency Hopping Yes
Frequency Hopping Speed Fast/Normal
Fast Profile Switching Yes
Multi-Chip Synchronization Yes
Digital Pre-Distortion Yes
Automatic Gain Control Yes
Closed Loop Gain Control Yes
Monitor Mode Yes
Power Saving Modes Yes
ADC Option HP/LP
External LO Option Yes
1
ADRV9005 can support Tx tracking cals when configured for TDD profiles. Not available during FDD operation.
analog.com
ADRV9003 ADRV9004
1T2R 2T2R
30 MHz to 6 GHz 30 MHz to 6 GHz
12kHz to 40 MHz 12kHz to 40 MHz
Yes Yes
Yes Yes
Yes Yes
Fast/Normal Fast/Normal
Yes Yes
Yes Yes
No No
Yes Yes
Yes Yes
Yes Yes
Yes Yes
HP/LP HP/LP
Yes Yes
ADRV9001
ADRV9005 ADRV9006
1T1R 2T2R
30 MHz to 6 GHz 30 MHz to 6 GHz
12kHz to 40 MHz 12kHz to 40 MHz
Yes Yes
1
Yes Yes
Yes Yes
Fast/Normal Normal
Yes No
Yes Yes
Yes No
Yes Yes
Yes Yes
Yes No
Yes Yes
HP/LP LP
Yes No
