PRINTED CIRCUIT BOARD LAYOUT RECOMMENDATIONS
Table 122. FMC Pinout Mapping Used by ADRV9001 Evaluation Board
Schematic Net Name
FPGA_REF_CLK+
FPGA_REF_CLK-
DEV_CLK_OUT
SM_FAN_TACH
RX1_DCLK_OUT+
RX1_DCLK_OUT-
RX1_STROBE_OUT+
RX1_STROBE_OUT-
RX1_IDATA_OUT+
RX1_IDATA_OUT-
RX1_QDATA_OUT+
RX1_QDATA_OUT-
DGPIO_13_TX1_DCLK_OUT+
DGPIO_12_TX1_DCLK_OUT-
TX1_DCLK_IN+
TX1_DCLK_IN-
TX1_STROBE_IN+
TX1_STROBE_IN-
TX1_IDATA_IN+
TX1_IDATA_IN-
TX1_QDATA_IN+
TX1_QDATA_IN-
RX2_DCLK_OUT+
RX2_DCLK_OUT-
RX2_STROBE_OUT+
RX2_STROBE_OUT-
RX2_IDATA_OUT+
RX2_IDATA_OUT-
RX2_QDATA_OUT+
RX2_QDATA_OUT-
DGPIO_15_TX2_DCLK_OUT+
DGPIO_14_TX2_DCLK_OUT-
TX2_DCLK_IN+
TX2_DCLK_IN-
TX2_STROBE_IN+
TX2_STROBE_IN-
TX2_IDATA_IN+
TX2_IDATA_IN-
TX2_QDATA_IN+
TX2_QDATA_IN-
RX1_ENABLE
RX2_ENABLE
TX1_ENABLE
TX2_ENABLE
SPI_EN
SPI_CLK
SPI_DIO
SPI_DO
MODE
analog.com
FMC Connector Mappings
G02-FMC_CLK1_M2C_P
G03-FMC_CLK1_M2C_N
H04-FMC_CLK0_M2C_P
H05-FMC_CLK0_M2C_N
G06-FMC_LA00_CC_P
G07-FMC_LA00_CC_N
H07-FMC_LA02_P
H08-FMC_LA02_N
G09-FMC_LA03_P
G10-FMC_LA03_N
H10-FMC_LA04_P
H11-FMC_LA04_N
D08-FMC_LA01_CC_P
D09-FMC_LA01_CC_N
H13-FMC_LA07_P
H14-FMC_LA07_N
C10-FMC_LA06_P
C11-FMC_LA06_N
G12-FMC_LA08_P
G13-FMC_LA08_N
D11-FMC_LA05_P
D12-FMC_LA05_N
D20-FMC_LA17_CC_P
D21-FMC_LA17_CC_N
H25-FMC_LA21_P
H26-FMC_LA21_N
G21-FMC_LA20_P
G22-FMC_LA20_N
H22-FMC_LA19_P
H23-FMC_LA19_N
C22-FMC_LA18_CC_P
C23-FMC_LA18_CC_N
G24-FMC_LA22_P
G25-FMC_LA22_N
H28-FMC_LA24_P
H29-FMC_LA24_N
D23-FMC_LA23_P
D24-FMC_LA23_N
G27-FMC_LA25_P
G28-FMC_LA25_N
C14-FMC_LA10_P
D27-FMC_LA26_N
D14-FMC_LA09_P
G30-FMC_LA29_P
H19-FMC_LA15_P
G15-FMC_LA12_P
G31-FMC_LA29_N
G16-FMC_LA12_N
D17-FMC_LA13_P
