POWER-SUPPLY RECOMMENDATIONS
Table 125. Instructions Explaining How to Handle ADRV9001 Unused Pins (Continued)
Pin No.
G12
G14, H14
H2
H3
H4
H5
H7
H8
H10
H11
H12
H13
K1
K2
K3
K4
K5
K6 to K11, L4 to L6, L9 to L11
K12
K13
K14
L1
L2
L3
L7, L8
L12
L13
L14
M1
M2
M3
M4
M5
M6
M7
M8
M9
M10
M11
M12
M13
M14
N1
N2
N3
N4
N5
analog.com
Type Mnemonic
Input VTX1LO_1P3
Output TX1+, TX1-
Input VANA2_1P8
Output VTX2LO_1P0
Input AUXADC_3
Output VCLKVCO_1P0
Output VCONV_1P0
Input VCONV_1P3
Output VAUXVCO_1P0
Input AUXADC_0
Output VTX1LO_1P0
Input VANA1_1P8
Input SPI_CLK
Input/Output SPI_DIO
Input RX2_EN
Input VSSA/TESTCK+
Input VSSA/TESTCK-
Input/Output DGPIO_xx
Input RX1_EN
Input RESETB
Output GP_INT
Input SPI_EN
Output SPI_DO
Input TX2_EN
Input VDIG_1P0
Input TX1_EN
Input MODE
Output DEV_CLK_OUT
Output RX2_IDATA_OUT-
Output RX2_IDATA_OUT+
Output RX2_DCLK_OUT-
Output RX2_DCLK_OUT+
Input/Output DGPIO_15/TX2_DCLK_OUT+
Input/Output DGPIO_14/TX2_DCLK_OUT-
Input VDIGIO_1P8
Output VDIG_0P9
Input/Output DGPIO_12/TX1_DCLK_OUT-
Input/Output DGPIO_13/TX1_DCLK_OUT+
Output RX1_DCLK_OUT+
Output RX1_DCLK_OUT-
Output RX1_IDATA_OUT+
Output RX1_IDATA_OUT-
Output RX2_STROBE_OUT-
Output RX2_STROBE_OUT+
Output RX2_QDATA_OUT-
Output RX2_QDATA_OUT+
Input TX2_DCLK_IN+
ADRV9001
Unused Instructions
Not applicable.
Do not connect.
Not applicable.
Connect to VSSA when unused.
Do not connect.
Not applicable.
Not applicable.
Not applicable.
Not applicable.
Do not connect.
Not applicable.
Not applicable.
Not applicable.
Not applicable.
Do not connect.
Not applicable.
Not applicable.
Do not connect.
Do not connect.
Not applicable.
Do not connect.
Not applicable.
In SPI 3-wire mode, do not connect.
Do not connect.
Not applicable.
Do not connect.
Connect to VSSA.
Do not connect.
Do not connect.
Do not connect.
Do not connect.
Do not connect.
Do not connect.
Do not connect.
Not applicable.
Not applicable.
Do not connect.
Do not connect.
Do not connect.
Do not connect.
Do not connect.
Do not connect.
Do not connect.
Do not connect.
Do not connect.
Do not connect.
Do not connect.
