POWER-SUPPLY RECOMMENDATIONS
In cases where not all RF IOs or other interface pins are used in the end application, follow
unused pins.
Table 125. Instructions Explaining How to Handle ADRV9001 Unused Pins
Pin No.
A1, A2, A13, A14, B2 to B5, B10 to B13, C2,
C5, C10, C13, D1 to D6, D9 to D14, E6, E9,
F1 to F3, F6 to F9, F12 to F14, G2, G13, J1
to J14
A3, A4
A5
A6
A7
A8
A9
A10
A11, A12
B1, C1
B6
B7
B8
B9
B14, C14
C3, C4
C6
C7
C8
C9
C11, C12
D7, D8
E1
E2
E3, E12, F4, F5, F10, F11, G4, G6, G9, G11,
H6, H9
E4
E5
E7, E8
E10
E11
E13
E14
G1, H1
G3
G5
G7
G8
G10
analog.com
Type Mnemonic
Input VSSA
Input EXT_LO2+, EXT_LO2−
Input VRFVCO2_1P3
Input/Output VRFLO2_1P0
Input MODEA
Input RBIAS
Input/Output VRFLO1_1P0
Input VRFVCO1_1P3
Input EXT_LO1-, EXT_LO1+
Input RX2A-, RX2A+
Output VRFVCO2_1P0
Input AUXADC_2
Input AUXADC_1
Output VRFVCO1_1P0
Input RX1A-, RX1A+
Input RX2B+, RX2B-
Input/Output VANA2_1P0
Input VANA2_1P3
Input VANA1_1P3
Input/Output VANA1_1P0
Input RX1B-, RX1B+
Input MCS+, MCS-
Output VRX2LO_1P0
Input VRX2LO_1P3
Input/Output AGPIO_xx
Input VRFSYN2_1P3
Input VCLKSYN_1P3
Input DEV_CLK_IN+, DEV_CLK_IN-
Input VAUXSYN_1P3
Input VRFSYN1_1P3
Input VRX1LO_1P3
Output VRX1LO_1P0
Output TX2+, TX2-
Input VTX2LO_1P3
Input VCLKVCO_1P3
Input VCONV_1P8
Input VAGPIO_1P8
Input VAUXVCO_1P3
ADRV9001
Table 125 for recommendations on what to do with
Unused Instructions
Not applicable.
Connect to VSSA.
Connect to VSSA when unused.
Not applicable.
Not applicable.
Not applicable.
Not applicable.
Connect to VSSA when unused.
Connect to VSSA.
When accidentally enabled, bias voltage is present on
those inputs. Connect to VSSA through capacitor.
Connect to VSSA when unused.
Do not connect.
Do not connect.
Connect to VSSA when unused
When accidentally enabled, bias voltage is present on
those inputs. Connect to VSSA through capacitor.
When accidentally enabled, bias voltage is present on
those inputs. Connect to VSSA through capacitor.
Connect to VSSA when unused.
Connect to VSSA when unused.
Not applicable.
Not applicable.
When accidentally enabled, bias voltage is present on
these inputs. Connect to VSSA through capacitor.
Connect to VSSA.
Connect to VSSA when unused.
Connect to VSSA when unused.
Do not connect.
Connect to VSSA when unused.
Not applicable.
Not applicable.
Not applicable.
Connect to VSSA when unused.
Not applicable.
Not applicable.
Do not connect.
Connect to VSSA when unused.
Not applicable.
Not applicable.
Not applicable.
Not applicable.
