Model 2606B System SourceMeter® Instrument Reference Manual
Calibration commands
Command
calstate = smuX.cal.state
smuX.cal.unlock("password")
smuX.measure.calibratei(range,
cp1Measured, cp1Reference,
cp2Measured, cp2Reference)
smuX.measure.calibratev(range,
cp1Measured, cp1Reference,
cp2Measured, cp2Reference)
smuX.source.calibratei(range,
cp1Expected, cp1Reference,
cp2Expected, cp2Reference)
smuX.source.calibratev(range,
cp1Expected, cp1Reference,
cp2Expected, cp2Reference)
2606B-901-01 Rev. C November 2021
Description
Request calibration state:
smuX.CALSTATE_CALIBRATING
smuX.CALSTATE_LOCKED
smuX.CALSTATE_UNLOCKED
Unlock calibration (default password: KI0026XX)
Adjust current measurement range calibration*:
±range (measurement range to adjust).
cp1Measured (2606B measured value for calibration
point 1).
cp1Reference (reference measurement for calibration
point 1).
cp2Measured (2606B measured value for calibration
point 2).
cp2Reference (reference measurement for calibration
point 2).
Adjust voltage measurement range calibration*:
±range (measurement range to adjust).
cp1Measured (2606B measured value for calibration
point 1).
cp1Reference (reference measurement for calibration
point 1).
cp2Measured (2606B measured value for calibration
point 2).
cp2Reference (reference measurement for calibration
point 2).
Adjust current source range calibration*:
±range (source range to adjust).
cp1Expected (source value programmed for calibration
point 1).
cp1Reference (reference measurement for calibration
point 1).
cp2Expected (source value programmed for calibration
point 2).
cp2Reference (reference measurement for calibration
point 2).
Adjust voltage source range calibration*:
±range (source range to adjust).
cp1Expected (source value programmed for calibration
point 1).
cp1Reference (reference measurement for calibration
point 1).
cp2Expected (source value programmed for calibration
point 2).
cp2Reference (reference measurement for calibration
point 2)
Section 17: Calibration
17-17
