Section 15: TSP command reference
status.measurement.reading_overflow.*
This attribute contains the measurement event reading overflow summary register set.
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
Usage
measurementRegister = status.measurement.reading_overflow.condition
measurementRegister = status.measurement.reading_overflow.enable
measurementRegister = status.measurement.reading_overflow.event
measurementRegister = status.measurement.reading_overflow.ntr
measurementRegister = status.measurement.reading_overflow.ptr
status.measurement.reading_overflow.enable = measurementRegister
status.measurement.reading_overflow.ntr = measurementRegister
status.measurement.reading_overflow.ptr = measurementRegister
measurementRegister
Details
These attributes are used to read or write to the measurement event reading overflow summary
registers. Reading a status register returns a value. The binary equivalent of the returned value
indicates which register bits are set. The least significant bit of the binary number is bit B0, and the
most significant bit is bit B15. For example, assume the value 2 is returned for the enable register.
The binary equivalent is 0000 0000 0000 0010. This value indicates that bit B1 (SMUA) is set.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
contents (on page 10-1) and
this register are defined in the following table.
Bit Value
Not used
B0
status.measurement.reading_overflow.SMUA
B1
status.measurement.reading_overflow.SMUB
B2
Not used
B3 to B15
15-284
Model 2606B System SourceMeter® Instrument Reference Manual
Affected by Where saved
- - - -
Not applicable Not saved
Status reset Not saved
Status reset Not saved
Status reset Not saved
Status reset Not saved
The status of the measurement reading overflow summary register; a zero (0)
indicates no bits set (also send 0 to clear all bits); other values indicate various
bit settings
Enable and transition registers
Default value
- -
Not applicable
0
0
0
6 (All bits set)
Status register set
(on page 10-18). The individual bits of
Description
Not applicable.
Set bit indicates that an overflow
reading has been detected for SMU A.
Bit B1 decimal value: 2
Binary value: 0000 0010
Set bit indicates that an overflow
reading has been detected for SMU B.
Bit B2 decimal value: 4
Binary value: 0000 0100
Not applicable.
