Model 2606B System SourceMeter® Instrument Reference Manual
Set the IP address to be set automatically
When the TCP/IP configuration mode is set to Automatic, a DHCP server automatically sets the IP
address, subnet mask, and the default gateway. To use this option, a DHCP server must be available
on the network.
The following steps reset the TCP/IP configuration, which also resets the instrument password. This
allows remote access to LXI web page controls that may have been password-protected before
the reset.
To use the LAN RESET switch to select Automatic configuration:
1. Turn on instrument power.
2. Wait for the instrument to complete power up.
3. Insert a straightened paper clip into the recessed LAN RESET switch on the 2606B front panel,
pressing the switch briefly. The LAN status indicator illuminates when the connection is
established.
4. To find the IP address that was automatically applied, use the LXI Discovery Tool, a utility that is
available from the Resources tab of the
Set the LAN configuration to Manual
When you use the manual configuration method with fixed LAN configuration settings, the instrument
IP address, subnet mask, and gateway are set to the following fixed values:
•
IP address: 192.168.0.2
•
Gateway: 192.168.0.1
•
Subnet mask: 255.255.255.0
You may need to set up a point-to-point connection to use these settings. Refer to
point-to-point connection
The LAN settings persist when the instrument power is turned off and then turned on again.
2606B-901-01 Rev. C November 2021
LXI Consortium website
(on page 9-5).
Section 9: LAN concepts and settings
(lxistandard.org).
Establishing a
9-3
