Model 2606B System SourceMeter® Instrument Reference Manual
lan.status.gateway
This attribute contains the gateway address presently in use by the LAN interface.
Type
TSP-Link accessible
Attribute (R)
Yes
Usage
gatewayAddress = lan.status.gateway
gatewayAddress
Details
The value of gatewayAddress is a string that indicates the IP address of the gateway in dotted
decimal notation.
Example
print(lan.status.gateway)
Outputs the gateway address, such as:
192.168.0.1
Also see
lan.config.gateway
lan.status.ipaddress
This attribute contains the LAN IP address presently in use by the LAN interface.
Type
TSP-Link accessible
Attribute (R)
Yes
Usage
ipAddress = lan.status.ipaddress
ipAddress
Details
The IP address is a character string that represents the IP address assigned to the instrument.
Example
print(lan.status.ipaddress)
Outputs the LAN IP address currently in use, such as:
192.168.0.2
Also see
lan.config.ipaddress
2606B-901-01 Rev. C November 2021
Affected by
Not applicable
LAN gateway address presently being used
(on page 15-130)
Affected by
Not applicable
LAN IP address specified in dotted decimal notation
(on page 15-131)
Section 15: TSP command reference
Where saved
Default value
Not applicable
Not applicable
Where saved
Default value
Not applicable
Not applicable
15-139
