Section 15: TSP command reference
status.request_event
This attribute stores the service request (SRQ) event register.
Type TSP-Link accessible
Attribute (R) Yes
Usage
requestSRQEventRegister = status.request_event
requestSRQEventRegister
Details
This attribute is used to read the service request event register, which is returned as a numeric value.
Reading this register returns a value. The binary equivalent of the value of this attribute indicates
which register bits are set. In the binary equivalent, the least significant bit is bit B0, and the most
significant bit is bit B7. For example, if a value of 1.29000e+02 (which is 129) is read as the value of
this register, the binary equivalent is 1000 0001. This value indicates that bit B0 and bit B7 are set.
B7 B6
** >
1 0
* Least significant bit
** Most significant bit
The returned value can indicate one or more status events occurred.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
contents (on page 10-1) and
this register are defined in the following table.
Bit Value
status.MEASUREMENT_SUMMARY_BIT
B0
status.MSB
status.SYSTEM_SUMMARY_BIT
B1
status.SSB
status.ERROR_AVAILABLE
B2
status.EAV
status.QUESTIONABLE_SUMMARY_BIT
B3
status.QSB
status.MESSAGE_AVAILABLE
B4
status.MAV
status.EVENT_SUMMARY_BIT
B5
status.ESB
15-338
Model 2606B System SourceMeter® Instrument Reference Manual
Affected by
Not applicable
The status of the request event register; a zero (0) indicates no
bits set; other values indicate various bit settings
B5 B4 B3
> > >
0 0 0
Enable and transition registers
Where saved
Not saved
B2 B1 B0
> > *
0 0 1
(on page 10-18). The individual bits of
Description
Set summary bit indicates that an enabled event in
the Measurement Event Register has occurred.
Bit B0 decimal value: 1
Set summary bit indicates that an enabled event in
the System Summary Register has occurred.
Bit B1 decimal value: 2
Set summary bit indicates that an error or status
message is present in the Error Queue.
Bit B2 decimal value: 4
Set summary bit indicates that an enabled event in
the Questionable Status Register has occurred.
Bit B3 decimal value: 8
Set summary bit indicates that a response message
is present in the Output Queue.
Bit B4 decimal value: 16
Set summary bit indicates that an enabled event in
the Standard Event Status Register has occurred.
Bit B5 decimal value: 32
2606B-901-01 Rev. C November 2021
Default value
0
Status register set
