Section 15: TSP command reference
smuX.trigger.MEASURE_COMPLETE_EVENT_ID
This constant contains the measurement complete event number.
Type
TSP-Link accessible
Constant
Yes
Usage
eventID = smuX.trigger.MEASURE_COMPLETE_EVENT_ID
eventID
X
Details
Set the stimulus of any trigger object to the value of this constant to have the trigger object respond to
measure complete events from this SMU.
Example
trigger.timer[1].stimulus = smuX.trigger.MEASURE_COMPLETE_EVENT_ID
Trigger the timer when the SMU completes a measurement.
Also see
Triggering
(on page 7-1)
smuX.trigger.PULSE_COMPLETE_EVENT_ID
This constant contains the pulse complete event number.
Type
TSP-Link accessible
Constant
Yes
Usage
eventID = smuX.trigger.PULSE_COMPLETE_EVENT_ID
eventID
X
Details
Set the stimulus of any trigger object to the value of this constant to have the trigger object respond to
pulse complete events.
Example
trigger.timer[1].stimulus = smua.trigger.PULSE_COMPLETE_EVENT_ID
Trigger a timer when the SMU completes a pulse.
Also see
Triggering
(on page 7-1)
15-262
Model 2606B System SourceMeter® Instrument Reference Manual
Affected by
Where saved
The measurement complete event number
Source-measure unit (SMU) channel (for example,
smua.trigger.MEASURE_COMPLETE_EVENT_ID applies to SMU channel A)
Affected by
Where saved
The pulse complete event number
Source-measure unit (SMU) channel (for example,
smua.trigger.PULSE_COMPLETE_EVENT_ID applies to SMU channel A)
Default value
Default value
2606B-901-01 Rev. C November 2021
