Section 15: TSP command reference
Usage
operationRegister = status.operation.instrument.condition
operationRegister = status.operation.instrument.enable
operationRegister = status.operation.instrument.event
operationRegister = status.operation.instrument.ntr
operationRegister = status.operation.instrument.ptr
status.operation.instrument.enable = operationRegister
status.operation.instrument.ntr = operationRegister
status.operation.instrument.ptr = operationRegister
operationRegister
Details
These attributes are used to read or write to the operation status instrument summary registers.
Reading a status register returns a value. The binary equivalent of the returned value indicates which
register bits are set. The least significant bit of the binary number is bit B0, and the most significant bit
is bit B15. For example, if a value of 1.02600e+03 (which is 1,026) is read as the value of the
condition register, the binary equivalent is 0000 0100 0000 0010. This value indicates that bit B1 and
bit B10 are set.
B15 B14
** >
0 0
* Least significant bit
** Most significant bit
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
contents (on page 10-1) and
this register are defined in the following table.
Bit Value
Not used
B0
status.operation.instrument.SMUA
B1
status.operation.instrument.SMUB
B2
Not used
B3 to B9
status.operation.instrument.TRIGGER_BLENDER
B10
status.operation.instrument.TRGBLND
status.operation.instrument.TRIGGER_TIMER
B11
status.operation.instrument.TRGTMR
15-294
The status of the operation event register; a zero (0) indicates no bits set (also send
0 to clear all bits); other values indicate various bit settings
B13 B12 B11 B10
> > > >
0 0 0 1
Enable and transition registers
Model 2606B System SourceMeter® Instrument Reference Manual
B9 B8 B7 B6 B5
> > > >
0 0 0 0
(on page 10-18). The individual bits of
B4 B3 B2 B1
> > > > >
0 0 0 0 1
Status register set
Description
Not applicable.
Set bit indicates one or more
enabled bits for the operation status
SMU A summary register is set.
Bit B1 decimal value: 2
Set bit indicates one or more
enabled bits for the operation status
SMU B summary register is set.
Bit B2 decimal value: 4
Not applicable.
Set bit indicates one or more
enabled bits for the operation status
trigger blender summary register
is set.
Bit B10 decimal value: 1,024.
Set bit indicates one or more
enabled bits for the operation status
trigger timer summary register
is set.
Bit B11 decimal value: 2,048
2606B-901-01 Rev. C November 2021
B0
*
0
