Model 2606B System SourceMeter® Instrument Reference Manual
Bit Value
Not used
B6
status.OPERATION_SUMMARY_BIT
B7
status.OSB
In addition to the above constants, requestEventRegister can be set to the decimal equivalent of
the bits set. When more than one bit of the register is set, requestEventRegister contains the
sum of their decimal weights. For example, if 129 is returned, bits B0 and B7 are set (1 + 128).
Bit
Binary value
Decimal
Weights
Example
requestEventRegister = status.request_event
print(requestEventRegister)
Also see
status.condition
status.system.*
Status byte and service request (SRQ)
status.reset()
This function resets all bits in the status model.
Type TSP-Link accessible
Function Yes
Usage
status.reset()
Details
This function clears all status data structure registers (enable, event, NTR, and PTR) to their default
values. For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
register set contents
Example
status.reset()
Resets the instrument status model.
2606B-901-01 Rev. C November 2021
B7 B6
0/1 0/1
128 64
7 6
(2 ) (2 )
(on page 15-273)
(on page 15-342)
(on page 10-14)
Affected by
(on page 10-1) and
Description
Not applicable
Set summary bit indicates that an enabled event in
the Operation Status Register has occurred.
Bit B7 decimal value: 128
B5 B4 B3
0/1 0/1 0/1
32 16 8
5 4 3
(2 ) (2 ) (2 )
Reads the status request event register.
Sample output:
1.29000e+02
Converting this output (129) to its binary
equivalent yields 1000 0001.
Therefore, this output indicates that the set bits
of the status request event register are presently
B0 (MSB) and B7 (OSB).
Where saved
Enable and transition registers
Section 15: TSP command reference
B2 B1 B0
0/1 0/1 0/1
4 2 1
2 1 0
(2 ) (2 ) (2 )
Default value
Status
(on page 10-18).
15-339
