Section 15: TSP command reference
Bit Value
status.system2.NODE28
B14
Not used
B15
As an example, to set bit B0 of the system summary 2 enable register, set
status.system2.enable = status.system2.EXT.
In addition to the above constants, enableRegister can be set to the decimal value of the bit to
set. To set more than one bit of the register, set enableRegister to the sum of their decimal
values. For example, to set bits B11 and B14, set enableRegister to 18,432 (which is the sum of
2,048 + 16,384).
Bit
Binary value
Decimal
Weights
Bit
Binary value
Decimal
Weights
Example 1
enableRegister = status.system2.NODE25 + status.system2.NODE28
status.system2.enable = enableRegister
Uses constants to set bits B11 and B14 of the system summary 2 enable register.
Example 2
-- decimal 18432 = binary 0100 1000 0000 0000
enableRegister = 18432
status.system2.enable = enableRegister
Uses the decimal value to set bits B11 and B14 of the system summary 2 enable register.
Also see
status.system.*
status.system3.*
System summary and standard event registers
15-346
B7 B6
0/1 0/1
128 64
7 6
(2 ) (2 )
B15 B14
0/1 0/1
32,768 16,384
15 14
(2 ) (2 )
(on page 15-342)
(on page 15-347)
Model 2606B System SourceMeter® Instrument Reference Manual
Decimal value
16,384
Not applicable
B5 B4 B3
0/1 0/1 0/1
32 16 8
5 4 3
(2 ) (2 ) (2 )
B13 B12 B11
0/1 0/1 0/1
8,192 4,096 2,048
13 12 11
(2 ) (2 ) (2 )
(on page 10-5)
2606B-901-01 Rev. C November 2021
B2 B1 B0
0/1 0/1 0/1
4 2 1
2 1 0
(2 ) (2 ) (2 )
B10 B9 B8
0/1 0/1 0/1
1,024 512 256
10 9 8
(2 ) (2 ) (2 )
