Model 2606B System SourceMeter® Instrument Reference Manual
Bit Value
Not used
B0
status.measurement.instrument.SMUA
B1
status.measurement.instrument.SMUB
B2
Not used
B3 to B15
As an example, to set bit B1 of the measurement event instrument summary enable register, set
status.measurement.instrument.enable = status.measurement.instrument.SMUA.
In addition to the above constants, measurementRegister can be set to the decimal equivalent of
the bit to set. To set more than one bit of the register, set measurementRegister to the sum of
their decimal weights. For example, to set bits B1 and B2, set measurementRegister to 6 (which is
the sum of 2 + 4).
Example
status.measurement.instrument.enable =
status.measurement.instrument.SMUA
Also see
Measurement event registers
status.measurement.instrument.smuX.*
This attribute contains the registers of the measurement event SMU X summary register set.
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
2606B-901-01 Rev. C November 2021
(on page 10-22)
Affected by Where saved
- - - -
Not applicable Not saved
Status reset Not saved
Status reset Not saved
Status reset Not saved
Status reset Not saved
Section 15: TSP command reference
Description
Not applicable.
Set bit indicates one or more enabled bits
of the measurement event SMU A
summary register is set.
Bit B1 decimal value: 2
Binary value: 0000 0010
Set bit indicates one or more enabled bits
of the measurement event SMU B
summary register is set.
Bit B2 decimal value: 4
Binary value: 0000 0100
Not applicable.
Sets the SMU A bit of the
measurement event instrument
summary enable register using a
constant.
Default value
- -
Not applicable
0
0
0
387 (All bits set)
