Section 13: Introduction to TSP operation
Retrieving and modifying a factory script listing
The script listing for a factory script can be retrieved and modified. However, it cannot be saved as a
factory script. The modified script can be saved as a user script using the same name or a new name.
An imported factory script can only be reloaded into the 2606B as a user script.
The following function retrieves a script listing. The script code is output with the shell keywords
(loadscript or loadandrunscript and endscript):
script.factory.scripts.name.list()
Where: name is the name of the factory script.
An example that retrieves the script listing for a factory script named KISweep:
script.factory.scripts.KISweep.list()
KISweep factory script
The KISweep factory script provides simple sweep test programming and shows how to use the
sweeping function.
This script is made up of the following functions. Access these functions from the virtual front panel or
the remote interfaces. The following functions make up the KISweep factory script:
SweepILinMeasureV()
SweepIListMeasureV()
SweepILogMeasureV()
SweepVLinMeasureI()
SweepVListMeasureI()
SweepVLogMeasureI()
KIPulse factory script
The KIPulse factory script provides examples of how to generate pulses and to provide a simple
pulsing interface. Pulses can be generated using the functions listed below.
Please note the following information about the KIPulse factory script:
▪
This factory script only operates on the channels present in the instrument executing the pulse
functions. These functions do not operate correctly if you attempt to access instrument channels
over the TSP-Link
▪
The KIPulse factory scripts are general purpose examples that may not be suitable for all use
cases. Very short pulses (less than 1 ms pulse width) may require optimization of the examples
provided by the factory script in order to achieve settled measurements.
▪
The PulseIMeasureV() and PulseVMeasureI() functions may be accessed from the front
panel. The remaining functions may only be accessed remotely.
13-20
Model 2606B System SourceMeter® Instrument Reference Manual
(on page 15-353)
(on page 15-354)
(on page 15-355)
(on page 15-356)
(on page 15-358)
(on page 15-359)
®
interface.
