Section 15: TSP command reference
Example
local ivalues = {}
smua.source.rangev = 1
smua.source.levelv = 0
smua.measure.rangei = 0.01
smua.source.output = smua.OUTPUT_ON
for index = 1, 10 do
ivalues[index] = smua.measureiandstep(index / 10)
end
ivalues[11] = smua.measure.i()
Also see
smuX.measure.autorangeY
smuX.measure.Y()
smuX.source.autorangeY
smuX.trigger.source.limitY
smuX.trigger.source.linearY()
smuX.trigger.source.listY()
smuX.trigger.source.logY()
Sweep Operation
smuX.nvbufferY
This attribute contains a dedicated reading buffer.
Type TSP-Link accessible
Attribute (R) Yes
Usage
bufferVar = smuX.nvbufferY
bufferVar
X
Y
Details
Each SMU channel contains two dedicated reading buffers: smuX.nvbuffer1 and
smuX.nvbuffer2.
All routines that return measurements can also store them in either reading buffer. Overlapped
measurements are always stored in a reading buffer. Synchronous measurements return either a
single-point measurement or can be stored in a reading buffer if passed to the
measurement command.
The dedicated reading buffers can be saved to internal nonvolatile memory (to retain data between
power cycles) using the smuX.savebuffer() function.
Example
smua.measure.overlappedv(smua.nvbuffer1)
15-230
(on page 15-211)
(on page 15-228)
(on page 15-233)
(on page 15-264)
(on page 15-265)
(on page 15-266)
(on page 15-267)
(on page 5-34)
Affected by
Not applicable
The dedicated reading buffer
Source-measure unit (SMU) channel (for example, smua.nvbuffer1 applies to
SMU channel A)
SMU nonvolatile buffer (1 or 2)
Model 2606B System SourceMeter® Instrument Reference Manual
This use of the SMU channel A
measure and step function measures
current starting at a source value of
0 V. After each current measurement,
the source is stepped 100 mV for the
next current measurement. The final
source level is 1 V, where current is
again measured.
Where saved
See Details
Store voltage readings from SMU channel A
into SMU channel A dedicated reading
buffer 1.
2606B-901-01 Rev. C November 2021
Default value
Not applicable
