Section 15: TSP command reference
Example
smua.reset()
smua.source.rangev = 5
smua.source.rangei = 1
smua.source.levelv = 0
smua.measure.rangev = 5
smua.measure.rangei = 1
smua.measure.nplc = 0.01
smua.measure.autozero = smua.AUTOZERO_ONCE
smua.nvbuffer1.clear()
smua.nvbuffer1.appendmode = 1
smua.source.output = smua.OUTPUT_ON
f1, msg1 = ConfigPulseVMeasureI(smua, 0, 5, 1, 0.002, 0.2, 10, smua.nvbuffer1, 1)
if f1 == true then
f2, msg2 = InitiatePulseTest(1)
print("Initiate message:", msg2)
else
print("Config errors:", msg1)
end
Configure channel A to generate a pulse train. If no errors are encountered, initiate the pulse train. Channel A
pulses voltage from a bias level of 0 V to a pulse level of 5 V. The pulse level is present for 2 ms and the bias
level for 200 ms, with a 1 A limit setting. A total of 10 pulses is generated, and the measurement data is stored
in smua.nvbuffer1. This pulse train is assigned to tag = 1.
Also see
ConfigPulseIMeasureV()
ConfigPulseIMeasureVSweepLin()
ConfigPulseIMeasureVSweepLog()
ConfigPulseVMeasureI()
ConfigPulseVMeasureISweepLin()
ConfigPulseVMeasureISweepLog()
KIPulse factory script
15-114
Model 2606B System SourceMeter® Instrument Reference Manual
(on page 15-37)
(on page 15-39)
(on page 15-41)
(on page 15-43)
(on page 15-45)
(on page 15-47)
(on page 13-20)
