Model 2606B System SourceMeter® Instrument Reference Manual
In addition to the above constants, operationRegister can be set to the numeric equivalent of the
bit to set. To set more than one bit of the register, set operationRegister to the sum of their
decimal values. For example, to set bits B1 and B10, set operationRegister to 1,026 (which is
the sum of 2 + 1,024).
Bit
Binary value
Decimal
Weights
Bit
Binary value
Decimal
Weights
Example 1
operationRegister = status.operation.instrument.digio.trigger_overrun.LINE1 +
status.operation.instrument.digio.trigger_overrun.LINE10
status.operation.instrument.digio.trigger_overrun.enable = operationRegister
Uses constants to set bit B1 and bit B10 of the operation status digital I/O overrun enable register.
Example 2
operationRegister = 1026
status.operation.instrument.digio.trigger_overrun.enable = operationRegister
Uses the decimal value to set bit B1 and bit B10 of the operation status digital I/O overrun enable register.
Also see
Operation Status Registers
status.operation.instrument.digio.*
status.operation.instrument.lan.*
This attribute contains the operation status LAN summary register set.
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
2606B-901-01 Rev. C November 2021
B7 B6 B5
0/1 0/1 0/1
128 64 32
7 6 5
(2 ) (2 ) (2 )
B15 B14 B13
0/1 0/1 0/1
32,768 16,384 8,192
15 14 13
(2 ) (2 ) (2 )
(on page 10-7)
(on page 15-296)
Affected by Where saved
- - - -
Not applicable Not saved
Status reset Not saved
Status reset Not saved
Status reset Not saved
Status reset Not saved
Section 15: TSP command reference
B4 B3 B2
0/1 0/1 0/1
16 8 4
4 3 2
(2 ) (2 ) (2 )
B12 B11 B10
0/1 0/1 0/1
4,096 2,048 1,024
12 11 10
(2 ) (2 ) (2 )
Default value
- -
Not applicable
0
0
0
1027 (All bits set)
B1 B0
0/1 0/1
2 1
1 0
(2 ) (2 )
B9 B8
0/1 0/1
512 256
9 8
(2 ) (2 )
