Model 2606B System SourceMeter® Instrument Reference Manual
Usage
measurerange = bufferVar.measureranges[N]
measurerange
bufferVar
N
Details
The measureranges buffer recall attribute is like an array (a Lua table) of full-scale range values for
the measure range used when the measurement was made.
For dedicated reading buffers, all buffer attributes are saved to nonvolatile memory only when the
reading buffer is saved to nonvolatile memory.
Example 1
measurerange = smua.nvbuffer1.measureranges[1]
Store the measure range that was used to make reading number 1.
Example 2
printbuffer(1, 10, smua.nvbuffer1.measureranges)
Print the range values that were used for the first 10 readings saved in dedicated reading buffer 1.
Example output:
1.00000e-07, 1.00000e-07,
1.00000e-07, 1.00000e-07,
1.00000e-07, 1.00000e-07,
1.00000e-07, 1.00000e-07,
1.00000e-07, 1.00000e-07
Also see
bufferVar.measurefunctions
bufferVar.n (on page 15-28)
bufferVar.readings
bufferVar.sourcefunctions
bufferVar.sourceoutputstates
bufferVar.sourceranges
bufferVar.sourcevalues
bufferVar.statuses
bufferVar.timestamps
Reading buffers
2606B-901-01 Rev. C November 2021
The measurement range used to acquire reading number N in the specified buffer
The reading buffer; can be a dynamically allocated buffer (user-defined), or a
dedicated reading buffer (such as smua.nvbuffer1)
The reading number (1 to bufferVar.n)
(on page 15-25)
(on page 15-29)
(on page 15-30)
(on page 15-31)
(on page 15-31)
(on page 15-32)
(on page 15-34)
(on page 15-36)
(on page 6-1)
Section 15: TSP command reference
15-27
