Section 15: TSP command reference
Also see
Operation Status Registers
status.operation.instrument.tsplink.trigger_overrun.*
status.operation.instrument.tsplink.trigger_overrun.*
This attribute contains the operation status TSP-Link overrun register set.
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
Usage
operationRegister =
status.operation.instrument.tsplink.trigger_overrun.condition
operationRegister = status.operation.instrument.tsplink.trigger_overrun.enable
operationRegister = status.operation.instrument.tsplink.trigger_overrun.event
operationRegister = status.operation.instrument.tsplink.trigger_overrun.ntr
operationRegister = status.operation.instrument.tsplink.trigger_overrun.ptr
status.operation.instrument.tsplink.trigger_overrun.enable = operationRegister
status.operation.instrument.tsplink.trigger_overrun.ntr = operationRegister
status.operation.instrument.tsplink.trigger_overrun.ptr = operationRegister
operationRegister
Details
These attributes are used to read or write to the operation status TSP-link overrun registers. Reading
a status register returns a value. The binary equivalent of the returned value indicates which register
bits are set. The least significant bit of the binary number is bit B0, and the most significant bit is bit
B15. For example, if a value of 10 is read as the value of the condition register, the binary equivalent
is 0000 0000 0000 1010. This value indicates that bit B1 and bit B3 are set.
B15 B14
** >
0 0
* Least significant bit
** Most significant bit
A set bit indicates that the specified line generated an action overrun when triggered to generate an
output trigger.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
contents (on page 10-1) and
this register are defined in the following table.
15-316
(on page 10-7)
Affected by
- -
Not applicable
Status reset
Status reset
Status reset
Status reset
B13 B12 B11 B10
> > > >
0 0 0 0
Enable and transition registers
Model 2606B System SourceMeter® Instrument Reference Manual
(on page 15-316)
Where saved
- -
Not saved
Not saved
Not saved
Not saved
Not saved
The status of the operation status TSP-link overrun register; a
zero (0) indicates no bits set (also send 0 to clear all bits); other
values indicate various bit settings
B9 B8 B7 B6 B5
> > > >
0 0 0 0
(on page 10-18). The individual bits of
Default value
- -
Not applicable
0
0
0
14 (All bits set)
B4 B3 B2 B1
> > > > >
0 0 1 0 1
Status register set
2606B-901-01 Rev. C November 2021
B0
*
0
