Model 2606B System SourceMeter® Instrument Reference Manual
Bit
Value and description
status.operation.instrument.smuX.TRIGGER_OVERRUN
B10
status.operation.instrument.smuX.TRGOVR
Set bit indicates an enabled bit has been set in the operation status smuX trigger overrun event
register.
Bit B10 decimal value: 1,024
B11 to B15 Not used
As an example, to set bit B0 of the operation status SMU A summary enable register, set
status.operation.instrument.smua.enable =
status.operation.instrument.smua.CAL.
In addition to the above constants, operationRegister can be set to the numeric equivalent of the
bit to set. To set more than one bit of the register, set operationRegister to the sum of their
decimal weights. For example, to set bits B0 and B10, set operationRegister to 1,025 (which is
the sum of 1 + 1,024).
Bit
Binary value
Decimal
Weights
Bit
Binary value
Decimal
Weights
Example 1
status.operation.instrument.smua.enable = status.operation.instrument.smua.MEAS
Use a constant to set bit B4 of the operation status SMU A summary enable register.
Example 2
status.operation.instrument.smua.enable = 1025
Use the decimal value to set bits B0 and B10 of the operation status SMU A summary enable register.
Also see
Operation Status Registers
status.operation.instrument.smuX.trigger_overrrun.*
2606B-901-01 Rev. C November 2021
B7
B6
B5
0/1
0/1
0/1
128
64
32
7
6
5
(2
)
(2
)
(2
)
B15
B14
B13
0/1
0/1
0/1
32,768
16,384
8,192
15
14
13
(2
)
(2
)
(2
)
(on page 10-7)
(on page 15-306)
Section 15: TSP command reference
B4
B3
B2
0/1
0/1
0/1
16
8
4
4
3
2
(2
)
(2
)
(2
)
B12
B11
B10
0/1
0/1
0/1
4,096
2,048
1,024
12
11
10
(2
)
(2
)
(2
)
B1
B0
0/1
0/1
2
1
1
0
(2
)
(2
)
B9
B8
0/1
0/1
512
256
9
8
(2
)
(2
)
15-305
