Model 2606B System SourceMeter® Instrument Reference Manual
Usage
operationRegister =
status.operation.instrument.trigger_timer.trigger_overrun.condition
operationRegister =
status.operation.instrument.trigger_timer.trigger_overrun.enable
operationRegister =
status.operation.instrument.trigger_timer.trigger_overrun.event
operationRegister =
status.operation.instrument.trigger_timer.trigger_overrun.ntr
operationRegister =
status.operation.instrument.trigger_timer.trigger_overrun.ptr
status.operation.instrument.trigger_timer.trigger_overrun.enable =
operationRegister
status.operation.instrument.trigger_timer.trigger_overrun.ntr =
operationRegister
status.operation.instrument.trigger_timer.trigger_overrun.ptr =
operationRegister
operationRegister
Details
These attributes are used to read or write to the operation status trigger timer overrun registers.
Reading a status register returns a value. The binary equivalent of the returned value indicates which
register bits are set. The least significant bit of the binary number is bit B0, and the most significant bit
is bit B15. For example, if a value of 18 is read as the value of the condition register, the binary
equivalent is 0000 0000 0001 0010. This value indicates that bit B1 and bit B4 are set.
B15 B14
** >
0 0
* Least significant bit
** Most significant bit
A set bit indicates the specified timer generated an action overrun because it was still processing a
delay from a previous trigger when a new trigger was received.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
contents (on page 10-1) and
this register are defined in the following table.
2606B-901-01 Rev. C November 2021
B13 B12 B11 B10
> > > >
0 0 0 0
Enable and transition registers
The status of the operation status trigger timer trigger overrun
register; a zero (0) indicates no bits set (also send 0 to clear all
bits); other values indicate various bit settings
B9 B8 B7 B6 B5
> > > >
0 0 0 0
(on page 10-18). The individual bits of
Section 15: TSP command reference
B4 B3 B2 B1
> > > > >
0 1 0 0 1
Status register set
B0
*
0
