Section 15: TSP command reference
smuX.trigger.IDLE_EVENT_ID
This constant contains the idle event number.
Type TSP-Link accessible
Constant Yes
Usage
eventID = smuX.trigger.IDLE_EVENT_ID
eventID
X
Details
Set the stimulus of any trigger object to the value of this constant to have the trigger object respond to
idle events from this SMU.
Example
trigger.timer[1].stimulus = smua.trigger.IDLE_EVENT_ID
Trigger timer 1 when the SMU returns to the idle layer.
Also see
Triggering (on page 7-1)
smuX.trigger.initiate()
This function initiates a sweep operation.
Type TSP-Link accessible
Function Yes
Usage
smuX.trigger.initiate()
X
Details
This function causes the SMU to clear the four trigger model event detectors and enter its trigger
model (moves the SMU from the idle state into the arm layer).
To perform source actions during the sweep, before calling this function, it is necessary to configure
and enable one of the following sweep source actions:
•
smuX.trigger.source.linearY()
•
smuX.trigger.source.listY()
•
smuX.trigger.source.logY()
15-256
Model 2606B System SourceMeter® Instrument Reference Manual
Affected by Where saved
The idle event number
Source-measure unit (SMU) channel (for example,
smua.trigger.IDLE_EVENT_ID applies to SMU channel A)
Affected by Where saved
Source-measure unit (SMU) channel (for example, smua.trigger.initiate()
applies to SMU channel A)
Default value
Default value
