Section 15: TSP command reference
Also see
trigger.timer[N].clear()
trigger.timer[N].delay
trigger.timer[N].reset()
trigger.timer[N].delay
This attribute sets and reads the timer delay.
Type TSP-Link accessible
Attribute (RW) Yes
Usage
interval = trigger.timer[N].delay
trigger.timer[N].delay = interval
interval
N
Details
Once the timer is enabled, each time the timer is triggered, it uses this delay period.
Assigning a value to this attribute is equivalent to:
trigger.timer[N].delaylist = {interval}
This creates a delay list of one value.
Reading this attribute returns the delay interval that is used the next time the timer is triggered.
Example
trigger.timer[1].delay = 50e-6
Set the trigger timer 1 to delay for 50 µs.
Also see
trigger.timer[N].reset()
15-370
Model 2606B System SourceMeter® Instrument Reference Manual
(on page 15-369)
(on page 15-370)
(on page 15-373)
Affected by
Instrument reset
Recall setup
Trigger timer N reset
Delay interval in seconds (0.5 µs to 100 ks)
Trigger timer number (1 to 8)
(on page 15-373)
Where saved Default value
Not saved 10e-6 (10 µs)
