Model 2606B System SourceMeter® Instrument Reference Manual
smuX.source.func
This attribute contains the source function, which can be voltage or current.
Type TSP-Link accessible
Attribute (RW) Yes
Usage
sFunction = smuX.source.func
smuX.source.func = sFunction
sFunction
X
Details
Reading this attribute indicates the output function of the source for the specified SMU channel.
Setting this attribute configures the SMU channel as either a voltage source or a current source.
Example
smua.source.func = smua.OUTPUT_DCAMPS
Also see
smuX.source.levelY
smuX.source.output
smuX.source.highc
This attribute enables or disables high-capacitance mode.
Type TSP-Link accessible
Attribute (RW) Yes
Usage
highC = smuX.source.highc
smuX.source.highc = highC
highC
X
2606B-901-01 Rev. C November 2021
Affected by
SMU reset
Instrument reset
Recall setup
The source function; set to one of the following values:
▪
0 or smuX.OUTPUT_DCAMPS: Selects the current source function
▪
1 or smuX.OUTPUT_DCVOLTS: Selects the voltage source function
Source-measure unit (SMU) channel (for example, smua.source.func applies to
SMU channel A)
(on page 15-238)
(on page 15-243)
Affected by
SMU reset
Instrument reset
Recall setup
The state of the high-capacitance mode; set to one of the following values:
▪
0 or smuX.DISABLE: Disables high-capacitance mode
▪
1 or smuX.ENABLE: Enables high-capacitance mode
Source-measure unit (SMU) channel (for example, smua.source.highc applies
to SMU channel A)
Section 15: TSP command reference
Where saved Default value
Saved setup 1 (smuX.OUTPUT_DCVOLTS)
Sets the source function of SMU channel A
to be a current source.
Where saved Default value
Saved setup 0 (smuX.DISABLE)
15-237
