Model 2606B System SourceMeter® Instrument Reference Manual
Export a script to a computer
You can download a script from TSB Embedded to the host computer.
TSP scripts have the extension .tsp.
To export a script to a computer:
1. Select the script from the User Scripts list.
2. Select Export to PC. The file is saved as a download.
3. Use the procedure for your browser to work with the file.
Export a script to the instrument USB
You can save a script to a USB flash drive inserted into the USB connector on the front panel of
the instrument.
To export a script to a USB flash drive:
1. Insert a flash drive into the USB port on the front panel of the instrument.
2. Select the script from the User Scripts list.
3. Select Export to USB.
4. In the Export File Name box, enter the file name.
5. Select Export.
Reset the instrument using TSB Embedded
The reset option in TSB Embedded performs an abort operation followed by a reset() command.
Refer to
reset()
Send individual instrument commands with TSB Embedded
You can send individual commands to the instrument using TSB Embedded. The response from the
instrument appears in the Output box.
To send commands from the console:
1. Type the command in Console.
2. Press the Enter key to send the command to the instrument. The command is displayed in the
Output box. If there is a response to the command, it is displayed after the command.
To clear information from the Output box:
1. Right-click in the Output box.
2. Select Clear.
2606B-901-01 Rev. C November 2021
(on page 15-176) for additional information.
Section 14: Instrument programming
14-41
