Section 15: TSP command reference
Bit Value and description
Not used
B0 to B9
status.operation.instrument.trigger_timer.TRIGGER_OVERRUN
B10
status.operation.instrument.trigger_timer.TRGOVR
Set bit indicates one or more enabled bits for the operation status trigger timer overrun register is
set.
Bit B10 decimal value: 1,024
Binary value:
0100 0000 0000
B11 to B15 Not used
In addition to the above constants, operationRegister can be set to the numeric equivalent of the
bit to set. For example, to set bit B10, set operationRegister to 1024.
Example
status.operation.instrument.trigger_timer.enable = 1024
Uses the decimal value to set the TRGOVR bit of the operation status trigger timer summary enable register.
Also see
Operation Status Registers
status.operation.instrument.trigger_timer.trigger_overrun.*
status.operation.instrument.trigger_timer.trigger_overrun.*
This attribute contains the operation status trigger timer overrun register set.
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
15-312
Model 2606B System SourceMeter® Instrument Reference Manual
(on page 10-7)
Affected by Where saved
- - - -
Not applicable Not saved
Status reset Not saved
Status reset Not saved
Status reset Not saved
Status reset Not saved
(on page 15-312)
Default value
- -
Not applicable
0
0
0
510 (All bits set)
