smuX.trigger.source.stimulus
This attribute defines which event causes the source event detector to enter the detected state.
Type TSP-Link accessible
Attribute (RW) Yes
Usage
eventID = smuX.trigger.source.stimulus
smuX.trigger.source.stimulus = eventID
eventID
X
Details
Set this attribute to the event ID of any trigger event generator to wait for that event. When set, the
SMU waits for the event at the source event detector portion of the trigger model. To bypass waiting
for an event, set the value of this attribute to zero (0). Set eventID to one of the existing trigger
event IDs shown in the following table.
Trigger event IDs*
Event ID
smuX.trigger.SWEEPING_EVENT_ID
smuX.trigger.ARMED_EVENT_ID
smuX.trigger.SOURCE_COMPLETE_EVENT_ID
smuX.trigger.MEASURE_COMPLETE_EVENT_ID
smuX.trigger.PULSE_COMPLETE_EVENT_ID
smuX.trigger.SWEEP_COMPLETE_EVENT_ID
smuX.trigger.IDLE_EVENT_ID
digio.trigger[N].EVENT_ID
tsplink.trigger[N].EVENT_ID
lan.trigger[N].EVENT_ID
display.trigger.EVENT_ID
2606B-901-01 Rev. C November 2021
(on page 15-247)
(on page 15-250)
(on page 15-252)
(on page 15-256)
(on page 15-258)
Affected by
SMU reset
Instrument reset
Recall setup
Set to the event that triggers the end pulse source off action
Source-measure (SMU) channel (for example,
smua.trigger.source.stimulus applies to SMU channel A)
Section 15: TSP command reference
Where saved Default value
Not saved 0
Event description
Occurs when the source-measure unit (SMU) transitions from
the idle state to the arm layer of the trigger model
Occurs when the SMU moves from the arm layer to the
trigger layer of the trigger model
Occurs when the SMU completes a source action
Occurs when the SMU completes a measurement action
Occurs when the SMU completes a pulse
Occurs when the SMU completes a sweep
Occurs when the SMU returns to the idle state
Occurs when an edge is detected on a digital I/O line
Occurs when an edge is detected on a TSP-Link line
Occurs when the appropriate LXI trigger packet is received on
LAN trigger object N
Occurs when the TRIG key on the virtual front panel is
pressed
