Section 15: TSP command reference
Bit
Binary value
Decimal
Weights
Bit
Binary value
Decimal
Weights
Example
status.questionable.enable = status.questionable.OTEMP
Uses a constant to set the OTEMP bit of the questionable status enable register.
Also see
Questionable Status Registers
status.questionable.calibration.*
This attribute contains the questionable status calibration summary register set.
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
Usage
questionableRegister = status.questionable.calibration.condition
questionableRegister = status.questionable.calibration.enable
questionableRegister = status.questionable.calibration.event
questionableRegister = status.questionable.calibration.ntr
questionableRegister = status.questionable.calibration.ptr
status.questionable.calibration.enable = questionableRegister
status.questionable.calibration.ntr = questionableRegister
status.questionable.calibration.ptr = questionableRegister
questionableRegister
15-328
Model 2606B System SourceMeter® Instrument Reference Manual
B7 B6 B5
0/1 0/1 0/1
128 64 32
7 6 5
(2 ) (2 ) (2 )
B15 B14 B13
0/1 0/1 0/1
32,768 16,384 8,192
15 14 13
(2 ) (2 ) (2 )
(on page 10-12)
Affected by Where saved
- - - -
Not applicable Not saved
Status reset Not saved
Status reset Not saved
Status reset Not saved
Status reset Not saved
The status of the questionable status calibration summary register; a zero
(0) indicates no bits set (also send 0 to clear all bits); other values indicate
various bit settings
B4 B3 B2
0/1 0/1 0/1
16 8 4
4 3 2
(2 ) (2 ) (2 )
B12 B11 B10
0/1 0/1 0/1
4,096 2,048 1,024
12 11 10
(2 ) (2 ) (2 )
Default value
- -
Not applicable
0
0
0
6 (All bits set)
2606B-901-01 Rev. C November 2021
B1 B0
0/1 0/1
2 1
1 0
(2 ) (2 )
B9 B8
0/1 0/1
512 256
9 8
(2 ) (2 )
