Section 15: TSP command reference
status.operation.trigger_overrun.*
This attribute contains the operation status trigger overrun summary register set.
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
Usage
operationRegister = status.operation.trigger_overrun.condition
operationRegister = status.operation.trigger_overrun.enable
operationRegister = status.operation.trigger_overrun.event
operationRegister = status.operation.trigger_overrun.ntr
operationRegister = status.operation.trigger_overrun.ptr
status.operation.trigger_overrun.enable = operationRegister
status.operation.trigger_overrun.ntr = operationRegister
status.operation.trigger_overrun.ptr = operationRegister
operationRegister
Details
These attributes are used to read or write to the operation status trigger overrun summary registers.
Reading a status register returns a value. The binary equivalent of the returned value indicates which
register bits are set. The least significant bit of the binary number is bit B0, and the most significant bit
is bit B15. For example, if a value of 1.02600e+03 (which is 1,026) is read as the value of the
condition register, the binary equivalent is 0000 0100 0000 0010. This value indicates that bit B1 and
bit B10 are set.
B15 B14
** >
0 0
* Least significant bit
** Most significant bit
The bits in this register summarize events in other registers. A set bit in this summary register
indicates that an enabled event in one of the summarized registers is set.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
contents (on page 10-1) and
this register are defined in the following table.
15-322
Affected by
- -
Not applicable
Status reset
Status reset
Status reset
Status reset
The status of the operation status trigger overrun summary register; a zero (0)
indicates no bits set (also send 0 to clear all bits); other values indicate various
bit settings
B13 B12 B11 B10
> > > >
0 0 0 1
Enable and transition registers
Model 2606B System SourceMeter® Instrument Reference Manual
Where saved
- -
Not saved
Not saved
Not saved
Not saved
Not saved
B9 B8 B7 B6 B5
> > > >
0 0 0 0
(on page 10-18). The individual bits of
Default value
- -
Not applicable
0
0
0
31,750 (All bits set)
B4 B3 B2 B1
> > > > >
0 0 0 0 1
Status register set
2606B-901-01 Rev. C November 2021
B0
*
0
