Model 2606B System SourceMeter® Instrument Reference Manual
Example 2
-- decimal 18432 = binary 0100 1000 0000 0000
enableRegister = 18432
status.system4.enable = enableRegister
Uses a decimal value to set bit B11 and bit B14 of the system summary 4 enable register.
Also see
status.system3.*
status.system5.*
System summary and standard event registers
status.system5.*
These attributes manage the TSP-Link
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
Usage
enableRegister = status.system5.condition
enableRegister = status.system5.enable
enableRegister = status.system5.event
enableRegister = status.system5.ntr
enableRegister = status.system5.ptr
status.system5.enable = enableRegister
status.system5.ntr = enableRegister
status.system5.ptr = enableRegister
enableRegister
Details
In an expanded system (TSP-Link), these attributes are used to read or write to the system summary
registers. They are set using a constant or a numeric value, but are returned as a numeric value. The
binary equivalent of the value indicates which register bits are set. In the binary equivalent, the least
significant bit is bit B0, and the most significant bit is bit B15. For example, if a value of
1.30000e+02 (which is 130) is read as the value of the condition register, the binary equivalent is
0000 0000 1000 0010. This value indicates that bit B1 and bit B7 are set.
B15 B14
** >
0 0
* Least significant bit
** Most significant bit
2606B-901-01 Rev. C November 2021
(on page 15-347)
(on page 15-351)
®
system summary register of the status model for nodes 57 through 64.
Affected by
- -
Not applicable
Status reset
Status reset
Status reset
Status reset
The status of the system summary 5 register; a zero (0) indicates no bits set; other
values indicate various bit settings
B13 B12 B11 B10
> > > >
0 0 0 0
(on page 10-5)
Where saved
- -
Not saved
Not saved
Not saved
Not saved
Not saved
B9 B8 B7 B6 B5
> > > >
0 0 1 0
Section 15: TSP command reference
Default value
- -
Not applicable
0
0
0
510 (All bits set)
B4 B3 B2 B1
> > > > >
0 0 0 0 1
B0
*
0
