Section 15: TSP command reference
Also see
digio.trigger[N].assert()
digio.trigger[N].pulsewidth
digio.trigger[N].reset()
This function resets trigger values to their factory defaults.
Type TSP-Link accessible
Function Yes
Usage
digio.trigger[N].reset()
N
Details
This function resets the following attributes to factory default settings:
▪
digio.trigger[N].mode
▪
digio.trigger[N].pulsewidth
▪
digio.trigger[N].stimulus
It also clears digio.trigger[N].overrun.
Example
digio.trigger[3].mode = 2
digio.trigger[3].pulsewidth = 50e-6
digio.trigger[3].stimulus = digio.trigger[5].EVENT_ID
print(digio.trigger[3].mode, digio.trigger[3].pulsewidth,
digio.trigger[3].stimulus)
digio.trigger[3].reset()
print(digio.trigger[3].mode, digio.trigger[3].pulsewidth,
digio.trigger[3].stimulus)
Set the digital I/O trigger line 3 for a falling edge with a pulsewidth of 50 µs.
Use digital I/O line 5 to trigger the event on line 3.
Reset the line back to factory default values.
Output before reset:
2.00000e+00
Output after reset:
0.00000e+00
Also see
digio.trigger[N].mode
digio.trigger[N].overrun
digio.trigger[N].pulsewidth
digio.trigger[N].stimulus
15-60
Model 2606B System SourceMeter® Instrument Reference Manual
(on page 15-55)
(on page 15-59)
Affected by
Digital I/O trigger line (1 to 14)
5.00000e-05
1.00000e-05
(on page 15-57)
(on page 15-58)
(on page 15-59)
(on page 15-61)
Where saved
5.00000e+00
0.00000e+00
2606B-901-01 Rev. C November 2021
Default value
