Section 15: TSP command reference
Also see
Status byte and service request (SRQ)
status.condition
status.system.*
status.operation.*
These attributes manage the operation status register set of the status model.
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
Usage
operationRegister = status.operation.condition
operationRegister = status.operation.enable
operationRegister = status.operation.event
operationRegister = status.operation.ntr
operationRegister = status.operation.ptr
status.operation.enable = operationRegister
status.operation.ntr = operationRegister
status.operation.ptr = operationRegister
operationRegister
Details
These attributes read or write the operation status registers.
Reading a status register returns a value. The binary equivalent of the returned value indicates which
register bits are set. The least significant bit of the binary number is bit B0, and the most significant bit
is bit B15. For example, if a value of 2.04800e+04 (which is 20,480) is read as the value of the
condition register, the binary equivalent is 0101 0000 0000 0000. This value indicates that bit B14
(PROGRAM_RUNNING) and bit B12 (USER) are set.
B15 B14
** >
0 1
* Least significant bit
** Most significant bit
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
contents (on page 10-1) and
this register are defined in the following table.
15-290
(on page 10-14)
(on page 15-273)
(on page 15-342)
Affected by
- -
Not applicable
Status reset
Status reset
Status reset
Status reset
The status of the operation status register; a zero (0) indicates no bits set (also send
0 to clear all bits); other values indicate various bit settings
B13 B12 B11 B10
> > > >
0 1 0 0
Enable and transition registers
Model 2606B System SourceMeter® Instrument Reference Manual
Where saved
- -
Not saved
Not saved
Not saved
Not saved
Not saved
B9 B8 B7 B6 B5
> > > >
0 0 0 0
(on page 10-18). The individual bits of
Default value
- -
Not applicable
0
0
0
31,769 (All bits set)
B4 B3 B2 B1
> > > > >
0 0 0 0 0
Status register set
2606B-901-01 Rev. C November 2021
B0
*
0
