Tektronix KEITHLEY SourceMeter 2606B Reference Manual page 559

Section 15: TSP command reference
Details
When setting the script name, this attribute renames the script that the variable scriptVar
references.
This attribute must be either a valid Lua identifier or the empty string. Changing the name of a script
changes the index that is used to access the script in the script.user.scripts table. Setting the
attribute to an empty string removes the script from the table completely, and the script becomes an
unnamed script.
As long as there are variables referencing an unnamed script, the script can be accessed through
those variables. When all variables that reference an unnamed script are removed, the script is
removed from the runtime environment.
If the new name is the same as a name that is already used for another script, the name of the other
script is set to an empty string, and that script becomes unnamed.
Changing the name of a script does not change the name of any variables that reference that script.
The variables still reference the script, but the names of the script and variables may not match.
Example
test7 = script.new("display.clear() display.settext('Hello from my test')", "")
test7()
print(test7.name)
test7.name = "test7"
print(test7.name)
test7.save()
This example calls the script.new() function to create a script with no name, runs the script, names the
script test7, and then saves the script in nonvolatile memory.
Also see
Rename a script
script.new() (on page 15-180)
scriptVar.save()
scriptVar.run()
This function runs a script.
Type TSP-Link accessible
Function No
Usage
scriptVar.run()
scriptVar()
scriptVar
15-186
(on page 14-46)
(on page 15-187)
Affected by
The name of the variable that references the script
Model 2606B System SourceMeter® Instrument Reference Manual
Where saved
2606B-901-01 Rev. C November 2021
Default value
