Section 10: Status model
•
Bit B5, Command Error (CME): Set bit indicates that a command error has occurred. Command
errors include:
▪
IEEE Std 488.2 syntax error: The 2606B instrument received a message that does not follow
the defined syntax of IEEE Std 488.2.
▪
Semantic error: 2606B instrument received a command that was misspelled or received an
optional IEEE Std 488.2 command that is not implemented.
▪
The instrument received a Group Execute Trigger (GET) inside a program message.
•
Bit B6, User Request (URQ): Set bit indicates that the LOCAL key on the 2606B instrument front
panel was pressed.
•
Bit B7, Power ON (PON): Set bit indicates that the 2606B instrument has been turned off and
turned back on since the last time this register was read.
Commands to program and read the register are summarized below and also in the
summary (on page 10-3) table.
Standard event commands
Command
*ESR?
or
print(status.standard.event)
*ESE mask
or
status.standard.enable = mask
*ESE?
or
print(status.standard.enable)
10-20
Model 2606B System SourceMeter® Instrument Reference Manual
Figure 114: Standard Event Register
Description
Read Standard Event Status Register.
Program the Event Status Enable Register:
mask = 0 to 255
See Status register set contents
Read Event Status Enable Register.
Status function
(on page 10-1).
