Model 2606B System SourceMeter® Instrument Reference Manual
Use the ID button to identify the module
You can select the ID button to determine which module you are communicating with.
The ID button is below the menu on every page of the web interface.
To identify the module:
1. On the Home page, select the ID button. The button turns green and the LAN STATUS indicator
on the module blinks.
2. Select the ID button again to return the button to its original color and return the LAN STATUS
indicator to steady on.
Change the IP configuration through the web interface
You can change the LAN settings through the web interface on the instrument. The LAN settings you
can change include the IP address, subnet mask, gateway, and DNS address.
If you change the IP address through the web interface, the web interface tries to redirect to the IP
address that is configured in the instrument. In some cases, this may fail. This generally happens if
you switch from an IP address assignment that uses a static address to an IP address assignment
that uses a DHCP server. If this happens, you need to revert to either using the virtual front panel to
set the IP address or use an automatic discovery tool to determine the new IP address.
You can also change the IP configuration using TSP commands. See
page 9-1) for information.
2606B-901-01 Rev. C November 2021
Figure 15: Web interface Welcome page
Section 3: Instrument description
LAN concepts and settings (on
3-17
