Model 2606B System SourceMeter® Instrument Reference Manual
Bit Value and description
status.operation.CALIBRATING
B0
status.operation.CAL
Set bit indicates that the summary bit of the status.operation.calibrating register has
been set.
Bit B0 decimal value: 1
Not used
B1 to B2
status.operation.SWEEPING
B3
status.operation.SWE
Set bit indicates that the summary bit from the status.operation.sweeping register is set.
Bit B3 decimal value: 8
status.operation.MEASURING
B4
status.operation.MEAS
Set bit indicates that the summary bit of the status.operation.measuring register is set.
Bit B4 decimal value: 16
Not used
B5 to B9
status.operation.TRIGGER_OVERRUN
B10
status.operation.TRGOVR
Set bit indicates that the summary bit from the status.operation.trigger_overrun
register is set.
Bit B10 decimal value: 1,024
status.operation.REMOTE_SUMMARY
B11
status.operation.REM
Set bit indicates that the summary bit of the status.operation.remote register is set.
Bit B11 decimal value: 2,048
status.operation.USER
B12
Set bit indicates that the summary bit from the status.operation.user register is set.
Bit B12 decimal value: 4,096
status.operation.INSTRUMENT_SUMMARY
B13
status.operation.INST
Set bit indicates that the summary bit from the status.operation.instrument register is
set.
Bit B13 decimal value: 8,192
status.operation.PROGRAM_RUNNING
B14
status.operation.PROG
Set bit indicates that a command or program is running.
Bit B14 decimal value: 16,384
Not used
B15
As an example, to set bit B12 of the operation status enable register, set
status.operation.enable = status.operation.USER.
In addition to the above constants, operationRegister can be set to the numeric equivalent of the
bit to set. To set more than one bit of the register, set operationRegister to the sum of their
decimal weights. For example, to set bits B12 and B14, set operationRegister to 20,480 (which
is the sum of 4,096 + 16,384).
