Section 15: TSP command reference
Also see
Measurement event registers
status.measurement.instrument.smuX.*
status.measurement.instrument.*
This attribute contains the registers of the measurement event instrument summary register set.
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
Usage
measurementRegister = status.measurement.instrument.condition
measurementRegister = status.measurement.instrument.enable
measurementRegister = status.measurement.instrument.event
measurementRegister = status.measurement.instrument.ntr
measurementRegister = status.measurement.instrument.ptr
status.measurement.instrument.enable = measurementRegister
status.measurement.instrument.ntr = measurementRegister
status.measurement.instrument.ptr = measurementRegister
measurementRegister
Details
These attributes are used to read or write to the measurement event instrument summary registers.
Reading a status register returns a value. The binary equivalent of the returned value indicates which
register bits are set. The least significant bit of the binary number is bit B0, and the most significant bit
is bit B15. For example, assume the value 6 is returned for the enable register. The binary equivalent
is 0000 0000 0000 0110. This value indicates that bit B1 (SMUA) and bit B2 (SMUB) are set.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
contents (on page 10-1) and
this register are defined in the following table.
15-280
Model 2606B System SourceMeter® Instrument Reference Manual
(on page 10-22)
(on page 15-281)
Affected by Where saved
- - - -
Not applicable Not saved
Status reset Not saved
Status reset Not saved
Status reset Not saved
Status reset Not saved
The status of the measurement event instrument summary register; a zero (0)
indicates no bits set (also send 0 to clear all bits); other values indicate various
bit settings
Enable and transition registers
Default value
- -
Not applicable
0
0
0
6 (All bits set)
Status register set
(on page 10-18). The individual bits of
