Section 3: Instrument description
How to access the web interface
When the LAN and instrument establish a connection, you can open the web page for the instrument.
To access the web interface:
1. Open a web browser on the host computer.
2. Enter the IP address of the instrument in the address box of the web browser. For example, if the
instrument IP address is 192.168.1.101, enter 192.168.1.101 in the browser address box.
3. Press Enter on the computer keyboard to open the instrument web page.
4. If prompted, enter a user name and password. The default is admin for both.
If the web page does not open in the browser, see
Web interface Welcome page
The Welcome page provides information about the instrument. It includes:
•
The instrument model number, manufacturer, firmware revision number, and instrument
serial number.
•
LXI information.
•
LAN connection information.
•
The TCP Raw Socket number and Telnet Port number.
•
Instrument address strings.
•
Calibration dates.
•
The ID button, which helps you find the instrument if you have multiple instruments.
3-16
Model 2606B System SourceMeter® Instrument Reference Manual
LAN troubleshooting suggestions
2606B-901-01 Rev. C November 2021
(on page 12-6).
