Model 2606B System SourceMeter® Instrument Reference Manual
trigger.blender[N].stimulus[M]
This attribute specifies the events that trigger the blender.
Type TSP-Link accessible
Attribute (RW) Yes
Usage
eventID = trigger.blender[N].stimulus[M]
trigger.blender[N].stimulus[M] = eventID
eventID
N
M
Details
There are four stimulus inputs that can each select a different event. The eventID parameter can be
the event ID of any trigger event.
Use zero to disable the blender input.
The eventID parameter may be one of the existing trigger event IDs shown in the following table.
Trigger event IDs*
Event ID
smuX.trigger.SWEEPING_EVENT_ID
smuX.trigger.ARMED_EVENT_ID
smuX.trigger.SOURCE_COMPLETE_EVENT_ID
smuX.trigger.MEASURE_COMPLETE_EVENT_ID
smuX.trigger.PULSE_COMPLETE_EVENT_ID
smuX.trigger.SWEEP_COMPLETE_EVENT_ID
smuX.trigger.IDLE_EVENT_ID
digio.trigger[N].EVENT_ID
tsplink.trigger[N].EVENT_ID
lan.trigger[N].EVENT_ID
display.trigger.EVENT_ID
trigger.EVENT_ID
trigger.blender[N].EVENT_ID
trigger.timer[N].EVENT_ID
2606B-901-01 Rev. C November 2021
Affected by
Restore configuration
Instrument reset
Power cycle
Trigger blender N reset
The event that triggers the blender action; see Details
An integer representing the trigger event blender (up to six)
An integer representing the stimulus index (1 to 4)
Event description
Occurs when the source-measure unit (SMU) transitions from
the idle state to the arm layer of the trigger model
Occurs when the SMU moves from the arm layer to the
trigger layer of the trigger model
Occurs when the SMU completes a source action
Occurs when the SMU completes a measurement action
Occurs when the SMU completes a pulse
Occurs when the SMU completes a sweep
Occurs when the SMU returns to the idle state
Occurs when an edge is detected on a digital I/O line
Occurs when an edge is detected on a TSP-Link line
Occurs when the appropriate LXI trigger packet is received on
LAN trigger object N
Occurs when the TRIG key on the virtual front panel is
pressed
Occurs when a *TRG command is received on the remote
interface
USB only: Occurs when a USBTMC TRIGGER message is
received
VXI-11 only: Occurs with the VXI-11 command
device_trigger; reference the VXI-11 standard for
additional details on the device trigger operation
Occurs after a collection of events is detected
Occurs when a delay expires
Section 15: TSP command reference
Where saved Default value
Configuration script trigger.EVENT_NONE
