Model 2606B System SourceMeter® Instrument Reference Manual
Use the configuration
train and assign the configuration to the tag parameter (use QueryPulseConfig() to inspect
configured pulse trains). Use the initiation InitiatePulseTest() function to execute the pulse
trains assigned to its tag arguments. The conditions listed in the table below must be true for these
functions to execute successfully.
Conditions that must be true for successful function execution
Conditions for Config
functions:
Source autorange (I and V) off
Measure autorange (I and V) off
Measure NPLC < ton
Measure autozero OFF or ONCE
Use the KIPulse simple pulse functions
pulse-measure cycles.
The following functions make up the KIPulse factory script.
KIPulse tag parameter pulse functions
ConfigPulseIMeasureV()
ConfigPulseVMeasureI()
ConfigPulseIMeasureVSweepLin()
ConfigPulseVMeasureISweepLin()
ConfigPulseIMeasureVSweepLog()
ConfigPulseVMeasureISweepLog()
InitiatePulseTest()
InitiatePulseTestDual()
QueryPulseConfig()
KIPulse simple pulse functions
PulseIMeasureV()
PulseVMeasureI()
2606B-901-01 Rev. C November 2021
KIPulse tag parameter pulse functions
Conditions for InitiatePulseTest
functions
Output on
There is enough free space in the
buffer
Buffer append mode is on when
pulse train is >1 point
(on page 13-21) to specify and perform a specified number of
(on page 15-37)
(on page 15-43)
(on page 15-39)
(on page 15-45)
(on page 15-41)
(on page 15-47)
(on page 15-113)
(on page 15-115)
(on page 15-174)
(on page 15-172)
(on page 15-173)
Section 13: Introduction to TSP operation
(on page 13-21) to configure a pulse
Conditions for
InitiatePulseTestDual functions
Output on
There is enough free space in the
buffer
Buffer append mode is on when
pulse train is >1 point
Separate unique source-measure
units (SMUs) for each tag
Same NPLC setting for each tag
Same toff for each tag
