Section 15: TSP command reference
Bit
Binary value
Decimal
Weights
Bit
Binary value
Decimal
Weights
Example 1
enableRegister = status.system.NODE11 + status.system.NODE14
status.system.enable = enableRegister
Uses constants to set bits B11 and B14 of the system summary enable register.
Example 2
-- decimal 18432 = binary 0100 1000 0000 0000
enableRegister = 18432
status.system.enable = enableRegister
Uses the decimal value to set bits B11 and B14 of the system summary enable register.
Also see
status.system2.*
System summary and standard event registers
status.system2.*
These attributes manage the TSP-Link
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
15-344
B7 B6
0/1 0/1
128 64
7 6
(2 ) (2 )
B15 B14
0/1 0/1
32,768 16,384
15 14
(2 ) (2 )
(on page 15-344)
®
system summary register of the status model for nodes 15 through 28.
Affected by
- -
Not applicable
Status reset
Status reset
Status reset
Status reset
Model 2606B System SourceMeter® Instrument Reference Manual
B5 B4 B3
0/1 0/1 0/1
32 16 8
5 4 3
(2 ) (2 ) (2 )
B13 B12 B11
0/1 0/1 0/1
8,192 4,096 2,048
13 12 11
(2 ) (2 ) (2 )
(on page 10-5)
Where saved
- -
Not saved
Not saved
Not saved
Not saved
Not saved
2606B-901-01 Rev. C November 2021
B2 B1 B0
0/1 0/1 0/1
4 2 1
2 1 0
(2 ) (2 ) (2 )
B10 B9 B8
0/1 0/1 0/1
1,024 512 256
10 9 8
(2 ) (2 ) (2 )
Default value
- -
Not applicable
0
0
0
32,767 (All bits set)
