Model 2606B System SourceMeter® Instrument Reference Manual
Also see
None
localnode.linefreq
This attribute contains the power line frequency setting that is used for NPLC calculations.
Type TSP-Link accessible
Attribute (RW) Yes
Usage
frequency = localnode.linefreq
localnode.linefreq = frequency
frequency
Details
To achieve optimum noise rejection when performing measurements at integer NPLC apertures, set
the line frequency attribute to match the frequency (50 Hz or 60 Hz) of the ac power line.
When using this command from a remote node, replace localnode with the node reference, for
example node[5].linefreq. When this attribute is set, the localnode.autolinefreq attribute
is automatically set to false. You can have the instrument automatically detect the ac power line
frequency and set this attribute with the line frequency detected when the instrument power is turned
on by setting the localnode.autolinefreq attribute to true.
Example 1
frequency = localnode.linefreq
Example 2
localnode.linefreq = 60
Also see
localnode.autolinefreq
localnode.model
This attribute stores the model number.
Type TSP-Link accessible
Attribute (R) Yes
Usage
model = localnode.model
model
2606B-901-01 Rev. C November 2021
Affected by
Not applicable
An integer representing the detected or specified line frequency of the instrument
Reads line frequency setting.
Sets the line frequency to 60 Hz.
(on page 15-153)
Affected by
Not applicable
The model number of the instrument
Section 15: TSP command reference
Where saved Default value
Nonvolatile memory 60 (60 Hz)
Where saved Default value
Not applicable Not applicable
15-155
