Model 2606B System SourceMeter® Instrument Reference Manual
Example
questionableRegister = status.questionable.instrument.smua.CAL +
status.questionable.instrument.smua.UO
status.questionable.instrument.smua.enable = questionableRegister
Uses constants to set bit B8 and bit B9 of the questionable status SMU A summary enable register.
Also see
Questionable Status Registers
status.operation.*
status.questionable.over_temperature.*
This attribute contains the questionable status over temperature summary register set.
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
Usage
questionableRegister = status.questionable.over_temperature.condition
questionableRegister = status.questionable.over_temperature.enable
questionableRegister = status.questionable.over_temperature.event
questionableRegister = status.questionable.over_temperature.ntr
questionableRegister = status.questionable.over_temperature.ptr
status.questionable.over_temperature.enable = questionableRegister
status.questionable.over_temperature.ntr = questionableRegister
status.questionable.over_temperature.ptr = questionableRegister
operationRegister
Details
These attributes are used to read or write to the questionable status over temperature summary
registers. Reading a status register returns a value. The binary equivalent of the returned value
indicates which register bits are set. The least significant bit of the binary number is bit B0, and the
most significant bit is bit B15.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
contents (on page 10-1) and
this register are defined in the following table.
2606B-901-01 Rev. C November 2021
(on page 10-12)
(on page 15-290)
Affected by
- -
Not applicable
Status reset
Status reset
Status reset
Status reset
The status of the questionable status over temperature summary register; a
zero (0) indicates no bits set (also send 0 to clear all bits); other values indicate
various bit settings
Enable and transition registers
Section 15: TSP command reference
Where saved Default value
- - - -
Not saved Not applicable
Not saved 0
Not saved 0
Not saved 0
Not saved 6 (All bits set)
(on page 10-18). The individual bits of
Status register set
15-333
