Model 2606B System SourceMeter® Instrument Reference Manual
status.system4.*
These attributes manage the TSP-Link
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
Usage
enableRegister = status.system4.condition
enableRegister = status.system4.enable
enableRegister = status.system4.event
enableRegister = status.system4.ntr
enableRegister = status.system4.ptr
status.system4.enable = enableRegister
status.system4.ntr = enableRegister
status.system4.ptr = enableRegister
enableRegister
Details
In an expanded system (TSP-Link), these attributes are used to read or write to the system summary
registers. They are set using a constant or a numeric value but are returned as a numeric value. The
binary equivalent of the value indicates which register bits are set. In the binary equivalent, the least
significant bit is bit B0, and the most significant bit is bit B15. For example, if a value of
1.29000e+02 (which is 129) is read as the value of the condition register, the binary equivalent is
0000 0000 1000 0001. This value indicates that bit B0 and bit B7 are set.
B15 B14
** >
0 0
* Least significant bit
** Most significant bit
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
contents (on page 10-1) and
this register are defined in the following table.
2606B-901-01 Rev. C November 2021
®
system summary register of the status model for nodes 43 through 56.
Affected by
- -
Not applicable
Status reset
Status reset
Status reset
Status reset
The status of the system summary 4 register; a zero (0) indicates no bits set; other
values indicate various bit settings
B13 B12 B11 B10
> > > >
0 0 0 0
Enable and transition registers
Where saved
- -
Not saved
Not saved
Not saved
Not saved
Not saved
B9 B8 B7 B6 B5
> > > >
0 0 1 0
(on page 10-18). The individual bits of
Section 15: TSP command reference
Default value
- -
Not applicable
0
0
0
32,767 (All bits set)
B4 B3 B2 B1
> > > > >
0 0 0 0 0
Status register set
B0
*
1
