Model 2606B System SourceMeter® Instrument Reference Manual
Trigger event IDs*
Event ID
trigger.timer[N].EVENT_ID
trigger.generator[N].EVENT_ID
* Use the name of the trigger event ID to set the stimulus value rather than the numeric value. Using the name
makes the code compatible for future upgrades (for example, if the numeric values must change when
enhancements are added to the instrument).
Example
smua.trigger.endpulse.action = smua.SOURCE_IDLE
smua.trigger.endpulse.stimulus = trigger.timer[1].EVENT_ID
Configure the end pulse action to achieve a pulse and select the event, trigger.timer[1].EVENT_ID, that
causes the arm event detector to enter the detected state.
Also see
Triggering (on page 7-1)
smuX.trigger.endsweep.action
This attribute sets the action of the source at the end of a sweep.
Type TSP-Link accessible
Attribute (RW) Yes
Usage
action = smuX.trigger.endsweep.action
smuX.trigger.endsweep.action = action
action
X
Details
Use this attribute to configure the source action at the end of the sweep. The SMU can be
programmed to return to the idle source level or hold the last value of the sweep.
Example
smua.trigger.endsweep.action = smua.SOURCE_IDLE
Sets SMU channel A to return the source back to the idle source level at the end of a sweep.
Also see
Triggering (on page 7-1)
2606B-901-01 Rev. C November 2021
Affected by Where saved
SMU reset Not saved
Instrument reset
Recall setup
The source action at the end of a sweep; set to one of the following values:
▪
0 or smuX.SOURCE_IDLE: Sets the source level to the programmed (idle) level
at the end of the sweep
▪
1 or smuX.SOURCE_HOLD: Sets the source level to stay at the level of the
last step
Source-measure unit (SMU) channel (for example,
smua.trigger.endsweep.action applies to SMU channel A)
Section 15: TSP command reference
Event description
Occurs when a delay expires
Occurs when the
trigger.generator[N].assert() function is
executed
Default value
0 (smuX.SOURCE_IDLE)
15-255
