Model 2606B System SourceMeter® Instrument Reference Manual
bufferVar.sourceoutputstates
This attribute indicates the state of the source output for readings that are stored in a specified buffer.
Type TSP-Link accessible
Attribute (R) Yes
Usage
state = bufferVar.sourceoutputstates[N]
state
bufferVar
N
Details
The bufferVar.sourceoutputstates buffer recall attribute is similar to an array (a Lua table) of
strings. This array indicates the state of the source output (Off or On) at the time of the
measurement.
For dedicated reading buffers, all buffer attributes are saved to nonvolatile memory only when the
reading buffer is saved to nonvolatile memory.
Example
printbuffer(1, 1, smua.nvbuffer1.sourceoutputstates)
Print the source output for the first reading stored in dedicated reading buffer 1.
Example output:
On
Also see
bufferVar.measurefunctions
bufferVar.measureranges
bufferVar.n (on page 15-28)
bufferVar.readings
bufferVar.sourcefunctions
bufferVar.sourceranges
bufferVar.sourcevalues
bufferVar.statuses
bufferVar.timestamps
Reading buffers
bufferVar.sourceranges
This attribute contains the source range that was used for readings stored in a specified reading buffer.
Type TSP-Link accessible
Attribute (R) Yes
2606B-901-01 Rev. C November 2021
Affected by
Clearing the buffer
The output state (Off or On) when reading N of the specified buffer was acquired
The reading buffer; can be a dynamically allocated buffer (user-defined), or a
dedicated reading buffer (such as smua.nvbuffer1)
The reading number (1 to bufferVar.n)
(on page 15-25)
(on page 15-26)
(on page 15-29)
(on page 15-30)
(on page 15-31)
(on page 15-32)
(on page 15-34)
(on page 15-36)
(on page 6-1)
Affected by
Clearing the buffer
Section 15: TSP command reference
Where saved Default value
See Details Not applicable
Where saved Default value
See Details Not applicable
