HELP MESSAGES
Error
Explanation
code
H171 User related
messages
H172
H175
H176
H177
H178
H180
H181
H182
H183
H184
H185
H186
H187
H192
Technical Manual
Dimax sensor not attached properly to C-
arm
Dimax sensor not attached properly to
Cephalostat
PC program selection in conflict with
selected ProMax X-ray unit program
Safety area limit violation.
One or more image layers will not be
exposed with these settings
Imaging impossible with selected set-
tings.
DEC not available
Exposure interrupted by the workstation
Timeout in image data transmission
Attached sensor is not suitable for the
selected program.
Move 3D sensor aside.
3D sensor not attached properly.
No IP address defined for 3D sensor.
Exposure interrupted by reconstruction
PC due to data transmission fault.
It is not possible to enable radiation or
PC communication (i410) when demo
licenses are switched on (i510).
Chapter C - HELP & ERROR MESSAGES
Comments
Sensor has not been attached
and/or locked in position.
Sensor has not been attached
and/or locked in position.
Wrong exposure mode has been
selected on the PC.
Change the values for layer thick-
ness, position or angle.
Change the exposure settings.
Change the exposure settings.
First switch off demo licenses
(i510), then enable radiation or
PC communication (i410).
