Planmeca ProMax Technical Manual page 361

ProMax INP (121-10-01), location of indicators
ProMax GUI, B/W (121-10-16), location of indicators
D1
D3
R efer ence N am e C olor / N or m al status
D 1 EXPLMP Yellow /off
D 3 RDYLMP Green /on
D 11 MEAS Green /?
D 12 +5Vdc_stby Green /on
MEAS Green /...
D 13
IN D IC A T O R S
D etails
lit when exp-key pressed
lit when possible to radiate
?
lit when +5V_STBY regulator delivering power
?
C O N N E C T O R S & JU MP E R S & S W IT C H E S
R efer ence N am e N or m al usage
J2 Plancan
-
J3 Ethernet -
J4 Main power -
J5 Plancan -
J6
Ethernet -
J7 +26Vdc -
Main switch -
J8,J9
J11 Exp.Switch -
J12
Exp.lamp -
J13 Stop switch -
D13
D11
D12
C O N N E C T O R S & JU MP E R S & S W IT C H E S
R efer ence N am e N or m al usage
J1
EPC Config -
J2 Solomon LCD -
J3 Plancan -
J4 Planar EL-display -
J5
Plancan -
Hitachi LCD -
J6
J7 EPC Config -
J8 PS/2 & RS232 -
J9
Exp.Switch -
J10 EL Display -
J11 Monitor mode -
J12 Touch Panel always
J13 Backlight always
D etails
-
-
-
-
-
-
-
-
D etails
-
-
-
-
-
-
exposure switch
-
monitor mode RS232
-
-
